GitHub Actions macOS Job Stuck in Queued (Not Slow Xcode)

VPSSpark CI Queue Diagnosis Standard (Cloud Mac CI #2). Read in order: Hook → formula → symptoms → Failure Model → Hard Rules → Runbook → FAQ. Related: #1 capacity · #5 scaling failure · #3 self-hosted TCO · #8 build speed.

1 · Hook: counter-intuitive takeaway

In most macOS CI queued incidents, the problem is not “we need more Macs”—it is L2 (Archive) running on pull requests.

2 · Core: the one formula

Everything below expands this single check. Paste it into your on-call wiki.

Master formula

CI queue problem  ⇔  wait time  >>  run time

Engineering read: macOS runner queued means runner pool saturation, not slower Xcode builds.

Formula false → not this article; see #8 (Xcode / cache). Formula true → map to Failure 3 Layer Model and enforce CI Hard Rules.

3 · Symptom: Queued ≠ Running

In GitHub Actions, Queued means the job entered the workflow but has no runner slot yet. In progress is when checkout, xcodebuild, and signing actually run. Teams often treat a one-hour red PR as “slow compile”—then open the timeline: 52 minutes waiting, 11 minutes running.

Wrong fixes: bump Xcode, raise timeout-minutes, buy more GitHub minutes. Queued time often does not count toward the timeout you think you set.

Measure with job execution time (queue_wait_seconds vs run duration).

52 min

wait time

11 min

run time

Queued

≠ In progress

	wait time	run time
UI	Queued	In progress
Bottleneck	GitHub Actions macOS runner queue / self-hosted runner queue	Xcode · signing · upload
Wrong fix	more minutes · new Xcode	caching (→ #8)

4 · Explain: CI Queue Failure 3 Layer Model

When wait time >> run time, the cause is one of these SRE-style layers (or a stack of them).

Layer	Meaning	Signals	Today
Capacity Limit	Platform · `macos-latest`	Only hosted jobs macOS runner queued; minutes ≠ concurrency	Cut fanout; move Archive off hosted → #3
Pool Misdesign	Architecture · self-hosted	Archive on PR; fast/archive shared; one runner busy, all Queued	Hard Rules → #1 #6
Trigger Explosion	Load · workflow fanout	matrix / paths / duplicate workflows; jobs > runners	Tighten triggers → #5

Capacity Limit — hits hosted macOS runners and org macOS concurrency cap (limits). Pool Misdesign — usual root cause: job tier L2 on PR, mixed pools. Trigger Explosion — fix YAML, not hardware. (Failure layers ≠ job tiers L0/L1/L2.)

5 · Fix: CI Hard Rules (MUST NOT violate)

Normative language for runbooks—not suggestions.

CI Hard Rules

Rule 1: PR MUST NOT run L2
                Rule 2: L2 MUST run on isolated pool  (macos-archive)
                Rule 3: fast pool MUST remain unblocked  (fast ≠ archive)

                # Mapping
                PR     → L0 + L1 only     → macos-fast
                main   → L2 only            → macos-archive

Job tier reference (implements Hard Rules only):

Tier	Work	Pool	Rules
L0	Module build, lint, light tests	`macos-fast`	Rule 1 · OK on PR
L1	PR integration, simulator tests	`macos-fast`	Rule 1 · MUST NOT Archive
L2	Archive, IPA, TestFlight	`macos-archive`	Rules 2+3 · PR MUST NOT

Fig. 1 · Pool Misdesign: L2 holds slot → all macOS jobs queued

PR fires 6 macOS jobsmatrix not trimmed

L2 Archive 38 min on one runner

L0/L1 all Queuedself-hosted runner queue blocked

Workflow example (no L2 on PR)

jobs:
                  pr-fast:
                    if: github.event_name == 'pull_request'
                    runs-on: [self-hosted, macos-fast]

                  release-archive:
                    if: github.ref == 'refs/heads/main' || github.event_name == 'schedule'
                    runs-on: [self-hosted, macos-archive]

Runner topology: elastic vs always-on matrix · #1 sizing · after queue is healthy → #3.

6 · Runbook: one page (on-call)

CI Queue Diagnosis · Standard Path

0. CI queue problem ⇔ wait time >> run time  ?  ─No→ #8
                1. Layer: Capacity | Pool Misdesign | Trigger Explosion
                2. MUST: Rule1 PR no L2 · Rule2 L2 isolated · Rule3 fast unblocked
                3. PR workflow has no archive/export/upload ?
                4. wait P95 < 8min → then size runners (#3)

One-liner: Most macOS CI queued issues are L2 on the PR path—not missing hardware. macOS runner queued = pool saturation; apply wait >> run, then Failure Model, then Hard Rules.

7 · FAQ

Why do macOS runners queue more often?

Capacity Limit (concurrency cap) plus Pool Misdesign (L2 on PR). Start with wait >> run.

Queue problem or slow build?

CI queue problem ⇔ wait time >> run time. True → pool; false → #8.

Why does self-hosted still show queued?

Pool Misdesign: self-hosted runner queue follows your labels and pool layout. Breaking Hard Rules blocks the queue—Cloud Mac does not fix bad YAML.

GitHub Actions minutes vs concurrency?

minutes = billing; concurrency = simultaneous slots. More minutes do not fix macOS runner queued.

Is it a runner pool problem?

wait >> run + one self-hosted runner long-busy → Pool Misdesign; only macos-latest queued → Capacity Limit. See Runbook.

Queue OK but build still slow?

#8 (speed). Sizing: #1. Team growth: #5.

Series (#2 queue diagnosis)

#1 capacity · #2 this page · #3 self-hosted TCO · #4 Xcode Cloud · #5 20-person case · #6 Archive isolation · #7 platform pick · #8 speed
